TRANSISTOR 2N6282 ELECTRONICS PARTS AMPS

$24.00 $17.00
Free Shipping!
There is only 1 item left in stock.

TRANSISTOR

Part: 2N6282

Category:
Discrete
-> Transistors
-> Bipolar

Description: Screening Options Available = ;; Polarity = NPN ;; Package = TO3 (TO204AA) ;; Vceo = 60V ;; IC(cont) = 20A ;; HFE(min) = 750 ;; HFE(max) = 18000 ;; @ Vce/ic = 3V / 10A ;; FT = 4MHz ;; PD = 160W

Company: Semelab Plc

Datasheet : download File size : 217 kB

Datasheet text preview:
2N6282

Dimensions in mm (inches).

25.15 (0.99) 26.67 (1.05) 10.67 (0.42) 11.18 (0.44) 1.52 (0.06) 3.43 (0.135)

6.35 (0.25) 9.15 (0.36)

Bipolar NPN Device in a Hermetically sealed TO3 Metal Package.

3 8 . 6 1 (1.52) 3 9 . 1 2 (1.54)

0 . 9 7 (0.060) 1 . 1 0 (0.043)

2 9 . 9 (1.177) 3 0 . 4 (1.197)

2 2 .2 3 (0 . 8 7 5 ) max.

1 6 . 6 4 (0.655) 1 7 . 1 5 (0.675)

1

2

Bipolar NPN Device. VCEO = 60V

3 (case) 3.84 (0.151) 4.09 (0.161) 7.92 (0.312) 12.70 (0.50)

IC = 20A
All Semelab hermetically sealed products can be processed in accordance with the requirements of BS, CECC and JAN, JANTX, JANTXV and JANS specifications.

TO3 (TO204AA) PINOUTS
1 Base 2 Emitter Case - Collector

Parameter VCEO* IC(CONT) hFE ft PD

Test Conditions

Min.

Typ.

Max. 60 20

Units V A Hz

NEW SURPLUS


NOTE:

ALL ELECTRONICS ARE UNTESTED

SOLD AS IS
