Texas Instruments
IC
INTEGRATED CIRCUIT
SN74S158N
QUADRUPLE 2-LINE TO 1-LINE DATA SELECTORS/ MULTIPLEXER' S
Military/High-Rel:NTech.:TTLCircuits
Per Package:4Input Chan./ Ckt:2No. of Addr. Lines:1VOL
Max.:0.5@Iol (A):20mt(PLH) Maximum (S):12nVIL
Max. (V):0.8VIH Min. (V):2.0Nom. Supp (V):5.0Maximum
Operating Temp (?C):70Package Style:DIPMounting
Style:T# Pins:16Pulsed Measurement?Description:
Inverting
SURPLUS
NOTE:
ALL ELECTRONICS ARE UNTESTED
SOLD AS IS
